TCAS 7.1 Compliant
EU OPS
6 Passenger Configuration
Will be Delivered with Fresh 48-Month Inspection
Total Time Since New | 3,257 Hours (As of January 2023) |
Total Landings Since New | 2,214 Landings |
Entry into Service Date | April 2, 2007 |
Home Base | Portugal |
Maintenance Tracking | CAMP |
Certification | EU OPS1 |
Left Engine | Right Engine | |
Description | Williams International FJ44-3A | |
Serial Number(s) | 141301 | 141300 |
Total Hours Since New | 3,218 Hours | 3,245 Hours |
Total Cycles Since New | 2,185 Landings | 2,205 Landings |
Program Coverage | TAP Advantage Blue |
The Cessna Citation CJ3 is equipped with an integrated, Pro Line 21 avionics suite. A general summary of this aircraft’s avionics suite is as follows:
Type of Unit | Quantity | Unit Description |
EFIS (Electronic Flight Instrument System) | 3-tube | ADF-3010 PFD and MFD |
FMS (Flight Management System) | Dual | Rockwell Collins FMS-3000 |
ADC (Air Data Computer) | Dual | Collins Aerospace ADC-3000 |
GPS (Global Positioning System) | Dual | GPS-4000A |
ECU (Engine Control Unit) | Single | Dual Channel FADEC |
NAV (Navigation Radio) | Dual | Collins NAV-4000 |
DME (Distance Measuring Equipment) | Single | Collins DME-4000 |
ADF (Automatic Direction Finder) | Dual | Collins NAV-4000 |
A/P (Autopilot) | Single | Collins |
VHF COM (Very High Freq. Communication) | Dual | Collins Aerospace VHF-4000 |
HF COM (High Frequency Communication) | Single | Collins HF-9031A |
AFIS (Airborne Flight Information System) | Single | Datalink XMWR-1000 |
RADAR | Single | Rockwell Collins RTA-800 |
RAD ALT (Radio Altimeter) | Single | Rockwell Collins ALT-4000 |
XPNDR (Transponder) | Dual | Rockwell Collins TDR-94D w/ 8.33kHz Spacing |
EGPWS (Enhanced Ground Proximity Warning System) | Single | Honeywell Mark VIII |
TCAS (Traffic Collision Avoidance System) | Single | Collins TTR-4000 w/ Change 7.1 |
CVR (Cockpit Voice Recorder) | Single | CVR L3 Harris FA2100 |
FDR (Flight Data Recorder) | Single | FDR L3 Harris FA2100 |
ELT (Emergency Locator Transmitter) | Single | Artex C406-N |
Inspection | Last Performed | Next Due |
12 Month (Inspection Doc 5) | September 2022 | September 2023 |
24 Month (Inspection Doc 6) | September 2022 | September 2024 |
36 Month (Inspection Doc 22) | September 2022 | September 2025 |
48 Month (Inspection Doc 8) | February 2019 | February 2023 |
72 Month (Inspection Doc 9) | February 2019 | February 2025 |
RVSM |
TCAS 7.1 |
ADS-B Out |
Description | |
Number of Passengers | Six Passengers + Belted Lav |
Refreshment Centre | Yes |
Forward Cabin Configuration | Four (4) Club Seats w/ Fold Out Tables |
Aft Cabin Configuration | 2 Single Forward-Facing Seats w/ Single Foldable Table |
Lavatory Location(s) | Aft |
Last Refurbishment Date | Original |
Base Paint Color(s) | White |
Stripe Color(s) | Black and Grey |
Last Painted Date | Original |
